1200 Series Off-Set T Heatshrink Shapes (VG Style)
Heat Shrink T Boots
Products
| Item # | Expanded (Min) H | Expanded (Min) J | P ±10% | R ±10% | Material |
|---|---|---|---|---|---|
| 1204-1-B7 | 0.51 | 0.26 | 2.20 | 1.30 | Semi-Rigid Flame Retarded Polyolefin |
| 1204-1-G | 0.51 | 0.26 | 2.20 | 1.30 | Fluid Resistant Flame Retarded Elastomer |
| 1204-1-H | 0.51 | 0.26 | 2.20 | 1.30 | Flexible Zero-Hal Limited Fire Hazard Material |
| 1204-1-J | 0.51 | 0.26 | 2.20 | 1.30 | Flexible Flame Retarded Polyolefin |
| 1204-1-L | 0.51 | 0.26 | 2.20 | 1.30 | Flexible Flame Retarded Fluro-Elastomer |
| 1216-1-B7 | 1.30 | 0.65 | 3.82 | 2.13 | Semi-Rigid Flame Retarded Polyolefin |
| 1216-1-G | 1.30 | 0.65 | 3.82 | 2.13 | Fluid Resistant Flame Retarded Elastomer |
| 1216-1-H | 1.30 | 0.65 | 3.82 | 2.13 | Flexible Zero-Hal Limited Fire Hazard Material |
| 1216-1-J | 1.30 | 0.65 | 3.82 | 2.13 | Flexible Flame Retarded Polyolefin |
| 1216-1-L | 1.30 | 0.65 | 3.82 | 2.13 | Flexible Flame Retarded Fluro-Elastomer |
| 1226-1-G | 1.20 | 0.70 | 3.20 | 1.87 | Fluid Resistant Flame Retarded Elastomer |
| 1226-1-H | 1.20 | 0.70 | 3.20 | 1.87 | Flexible Zero-Hal Limited Fire Hazard Material |
| 1226-1-L | 1.20 | 0.70 | 3.20 | 1.87 | Flexible Flame Retarded Fluro-Elastomer |
| 1226-1-B7 | 1.20 | 0.70 | 3.20 | 1.87 | Semi-Rigid Flame Retarded Polyolefin |
| 1226-1-J | 1.20 | 0.70 | 3.20 | 1.87 | Flexible Flame Retarded Polyolefin |
