1200 Series Off-Set T Heatshrink Shapes
Heat Shrink T Boots
Products
| Item # | Expanded (Min) H | Expanded (Min) J | P ±10% | R ±10% | Material |
|---|---|---|---|---|---|
| 1217-1-B7 | 0.39 | 0.24 | 2.24 | 0.75 | Semi-Rigid Flame Retarded Polyolefin |
| 1217-1-G | 0.39 | 0.24 | 2.24 | 0.75 | Fluid Resistant Flame Retarded Elastomer |
| 1217-1-H | 0.39 | 0.24 | 2.24 | 0.75 | Flexible Zero-Hal Limited Fire Hazard Material |
| 1217-1-J | 0.39 | 0.24 | 2.24 | 0.75 | Flexible Flame Retarded Polyolefin |
| 1217-1-L | 0.39 | 0.24 | 2.24 | 0.75 | Flexible Flame Retarded Fluro-Elastomer |
| 1222-1-B7 | 1.22 | 0.71 | 3.62 | 2.05 | Semi-Rigid Flame Retarded Polyolefin |
| 1222-1-G | 1.22 | 0.71 | 3.62 | 2.05 | Fluid Resistant Flame Retarded Elastomer |
| 1222-1-H | 1.22 | 0.71 | 3.62 | 2.05 | Flexible Zero-Hal Limited Fire Hazard Material |
| 1222-1-J | 1.22 | 0.71 | 3.62 | 2.05 | Flexible Flame Retarded Polyolefin |
| 1222-1-L | 1.22 | 0.71 | 3.62 | 2.05 | Flexible Flame Retarded Fluro-Elastomer |
| 1223-1-B7 | 1.16 | 0.38 | 3.67 | 2.23 | Semi-Rigid Flame Retarded Polyolefin |
| 1223-1-G | 1.16 | 0.38 | 3.67 | 2.23 | Fluid Resistant Flame Retarded Elastomer |
| 1223-1-H | 1.16 | 0.38 | 3.67 | 2.23 | Flexible Zero-Hal Limited Fire Hazard Material |
| 1223-1-J | 1.16 | 0.38 | 3.67 | 2.23 | Flexible Flame Retarded Polyolefin |
| 1223-1-L | 1.16 | 0.38 | 3.67 | 2.23 | Flexible Flame Retarded Fluro-Elastomer |
Visit the FDH Electronics online store and create an account for special pricing.
